HOW TO USE YOUR APPLIANCE
HOW TO USE YOUR APPLIANCE
8 Overview
8.1 Fascia
1
2 3
5
4
Key
1 Anolouge clock
2 Reset button
3 Mode selection button
4 Temperature adjustment
5 Display
8.2 Display
6
5
4
2
1
3
Key
1 Heating
2 OFF
3 Domestic hot water
4 DHW/CH water temperature/CH pressure
5 Symbol indicates temperature or pressure
6 Symbol indicates burner ON
