GLUX VSP-F2L4 User Manual

9
Function
IP Address
Language
> Data save
Function
# Save
Exit
Function
# Save Save Ok
Exit
X start For setting the initial horizontal display position of LED screen. The default
value is 0.
Y start: For setting the initial vertical display position of LED screen. The default
value is 0.
X Width: The pixel width per controller port.
Y Height: The pixel height per controller port.
ZOOM H(Horizontal zoom)
：
The actual output pixel width of horizontal scaling
from the input resolution’s horizontal pixel width.
ZOOM V(Vertical zoom)
：
The actual output pixel height of vertical scaling from the
input resolution’s vertical pixel height.
Screen on/off
（
Screen switch: Play or turn off the LED screen.
Freeze
（
Lock
）：
Suspend or display the LED screen.
Correct on/off
（
Calibration switch
）
: Turn on the switch for calibrated LED screen,
turn off the switch for uncalibrated LED screen, default value should be ON if your
screen have calibrated.
Rotate
：
Make the display image rotate 90 degrees, only valid for our
BAtn/MOtn/MOsn series products current now.
Reset
：
Reset brightness, position and some other parameters of screen.
2.2.3 Address
Setting the signal connect way and display address of the LED screen.
(Usually do not use this function in the keyboard to adjust Address)
Press SEL/SDI1 to enter the Save menu and
rotate the control knob to select the Save.
Then Select it, you will see the symbol #.
Rotate the control knob to Save. Then Press
SEND/DVI to send, and Press ESC/SDI2 to
exit

GLUX VSP-F2L4 Specifications

General

Brand	GLUX
Model	VSP-F2L4
Category	Controller
Language	English
