2.2.1 Product
Please select correct relative parameters of the product under the Product Option
Port: Select a connecting controller port.
Series: Select a style of the product.
Cut Signal: Cut or link the transmission signal of the VSP-F2L4 controller.
Test Mode: Test and check the color of the LED screen.
DMX512 on/off: Please select OFF if there is no DMX512 signal input to the
controller.
Mirror: Set mirror image display effect for LED screen.
Drive IC: Choose correct LED drive IC in your LED panel.
LED PIN1~LED PIN3: Define the pins color of LED lamp to avoid the display color
exchanged.
IN MODE: The mode of display card. Limit range means HDMI 0-235 level gray
mode, Full range means DVI 0-255 gray mode, the default mode is full range.
2.2.2 Spec (Adjust and set the parameters of LED screen)
Bright（Brightness）：Adjust the brightness of LED screen, such as the steps of adjust
brightness:
Input DVI 1920×1080 P 60
Output 1024×768 P60
Brightness 70 IC MBI5041
CYSN39 IP 192. 168. 0.6
Function
Product
> Spec
Address
Function
# Bright 60
X Start 0
Y Start 0
Then rotate the control knob to adjust the brightness level, and click the SEND/DVI to send,
at last save your setting in the save menu.
Press SETUP/HDMI to enter the parameter
setting mode, and rotate the control knob to
select the Spec. Option.
Press SEL/SDI1 to enter the parameter and rotate the
control knob to select the Bright, then press the
SEL/SDI1 key to enter, you can see the symbol #.
To Next Page
