GMC Terrain Owner Manual - 2011
10-16 Vehicle Care
3. Remove the four air cleaner
housing cover screws.
4. Pull straight up on the cover, and
while holding the cover, remove
the air cleaner filter.
5. Inspect or replace the air cleaner
filter.
How to Reinstall Engine Air
Cleaner/Filter
1. Install the air cleaner filter into
the air cleaner housing. The
outer air cleaner filter seal must
be fitted properly in the air
cleaner housing.
2. Align the air cleaner housing
cover tabs to the air cleaner
housing.
3. Install the air cleaner housing
cover using the four screws.
{
WARNING
Operating the engine with the air
cleaner/filter off can cause you
or others to be burned. The air
cleaner not only cleans the air; it
helps to stop flames if the engine
backfires. Use caution when
working on the engine and do not
drive with the air cleaner/filter off.
Notice: If the air cleaner/filter is
off, dirt can easily get into the
engine, which could damage it.
Always have the air cleaner/filter
in place when you are driving.
Cooling System
2.4 L L4 Engine
A. Engine Cooling Fan (Out
of View)
B. Engine Coolant Surge Tank
and Pressure Cap
