10-30 Vehicle Care
Wiper Blade Replacement
Windshield wiper blades should be
inspected for wear and cracking.
See Scheduled Maintenance on
page 11‑2 for more information.
Replacement blades come in
different types and are removed
in different ways. For proper type
and length, see Maintenance
Replacement Parts on page 11‑8.
Notice: Allowing the wiper blade
arm to touch the windshield when
no wiper blade is installed could
damage the windshield. Any
damage that occurs would not
be covered by your warranty. Do
not allow the wiper blade arm to
touch the windshield.
Front Wiper Blade
Replacement
To replace the front wiper blades:
1. Lift the wiper arm from the
windshield until no further
movement is possible.
2. Press the square button on the
top side, at the end of the wiper
arm, and pull the wiper blade out
of the end of the wiper arm.
3. Install the wiper blade connector
by sliding into the end of the
wiper arm until the square button
on the wiper blade clicks into
place with the wiper arm.
4. Place the wiper arm with the
wiper blade in place back on the
windshield.
Rear Wiper Blade Replacement
To replace the rear wiper blade:
1. Lift the wiper arm from the
liftgate glass until no further
movement is possible.
2. Hold the wiper arm at the tip with
one hand and hold the wiper
blade at the tip with the
other hand.
3. Pull down on the wiper blade.
The blade will pull away from
the arm.
4. Place the wiper blade into the
wiper arm aligning the blade
attachment rivet with the arm
attachment.
