Vehicle Care 10-45
Mini Fuses Usage
12
Heater, Ventilation
and Air Conditioning
Battery
13
Auxiliary Power
Front
14
Heater, Ventilation
and Air Conditioning
Ignition
15 Display
16
Body Control
Module 5
17
Auxiliary
Power Rear
18
Instrument Panel
Cluster Ignition
19
Personal Device
Interface Module
20
Body Control
Module 6
21
Special Equipment
Order Retained
Accessory Power
Mini Fuses Usage
22
Sensing and
Diagnostic Module
Ignition
23 Spare
24 Spare
25
Transmission Gear
Shift Position
Indicator
26 Spare
27 Spare
28 Spare
30
Body Control
Module 3
31 Amplifier
32
Discrete Logic
Ignition Switch
33
Communications
Integration Module
34
Body Control
Module 2
Mini Fuses Usage
35
Sensing and
Diagnostic Module
Battery
36
Data Link
Connection
37
Instrument Panel
Cluster Battery
38
Passenger Sensing
System Module
39 Spare
J‐Case
Fuses
Usage
29 Front Blower Motor
40
Body Control
Module 8
Relays Usage
41
Logistic Relay
(If Equipped)
42
Retained Accessory
Power Relay
