Vehicle Care 309
Fuses Usage
F2 Starter 1
F3 DC DC
transformer 1
F4 –
F5 –
F6 –
F7 DC DC
transformer 2
F8 Starter 3
F9 –
F10 –
F11 –
F12 Front wiper
F13 Starter 2
F14 LED/Automatic
headlamp leveling
(if equipped)
F15 Rear wiper 1
F16 –
F17 –
Fuses Usage
F18 Automatic
headlamp leveling
(if equipped)
F19 –
F20 –
F21 –
F22 Electronic brake
control module
F23 Parking/
Trailer lamp
F24 Right trailer
stoplamp/Turn
signal lamp
F25 Steering
column lock
F26 –
F27 Left trailer
stoplamp/Turn
signal lamp
F28 –
F29 –
F30 Washer pump
Fuses Usage
F31 Right low-beam
headlamp
F32 Left low-beam
headlamp
F33 Fog lamps
F34 Horn
F35 –
F36 Left high-beam
headlamp
F37 Right high-beam
headlamp
F38 Automatic
headlamp leveling
(if equipped)
F39 Transmission
control module 1
F40 Left rear bus
electrical center/
Ignition
F41 Instrument cluster
F42 HVAC
F43 Head-up display (if
equipped)
