310 Vehicle Care
Fuses Usage
F44 –
F45 –
F46 –
F47 –
F48 Rear wiper 2
F49 Interior rearview
mirror/Trailer
F50 Fuel system control
module
F51 Heated steering
wheel
F52 A/C clutch
F53 Transmission
range control
module
F54 Coolant pump
F55 –
F56 –
F57 Engine control
module/Ignition
F58 Transmission
control module/
Ignition
Fuses Usage
F59 Engine control
module battery
F60 Transmission
control module 2
F61 O2 sensor 1/
Aeroshutter
F62 Engine control
module – odd
F63 O2 sensor 2
F64 Engine control
module – even
F65 Engine control
module
powertrain 1
F66 Engine control
module
powertrain 2
F67 Powertrain TRCM
F68 –
F69 –
F70 –
F71 –
F72 –
Fuses Usage
F73 –
F74 –
F75 –
F76 –
F77 –
K1 Starter 1
K2 Run/Crank
K3 Starter 3
K4 LED/Automatic
headlamp (if
equipped)
K5 –
K6 Coolant pump
K7 Engine control
module
K8 A/C
K9 –
K10 Starter 2
