GMC Terrain 2011 - Fuse Block 1; Instrument Panel

Black plate (43,1)
GMC Terrain Owner Manual - 2011
Vehicle Care 10-43
J-Case
Fuses
Usage
4
Power
Windows – Right
5
Memory Seat
Module
6 Power Seat – Left
7
Instrument Panel
Fuse Block 1
8 Rear Defogger
9 Starter
10 AIR Pump Motor
11
Instrument Panel
Fuse Block 2
12 Sunroof
13
Antilock Brake
System Pump
J-Case
Fuses
Usage
14
Instrument Panel
Fuse Block 3
15
Power
Windows – Left
16
Antilock Brake
System Module
Mini Fuses Usage
17
Transmission
Control Module
Battery
18 Trailer Parking Light
19 AIR Pump Solenoid
20
Engine Control
Module Battery
21 Canister Vent
Mini Fuses Usage
22
Trailer Left Side
(If Equipped)
23 Lift Gate Module
24 Power Lumbar
25
Trailer Right Side
(If Equipped)
26
Rear Accessory
Power Outlet
27
Memory Mirror
Module
28
Regulated Voltage
Control Battery
Sensor
29 Front Wiper
30 Rear Wiper
31
Air Conditioning
Compressor
