GME TX3510S - General Operations; TX3510 S;TX3520 S Front Panel Controls; LCD Panel; Rear Panel

PAGE 6 I NSTRUCTI ON MA NUA L T X3510S / T X3520S / T X3540S
T X3510S / T X3520S / T X3540S I NSTRUCTI ON MA NUA L PAGE 7
REAR PANEL
TX3540S CONTROLLER MICROPHONE
TX3540S CONTROLLER LCD PANEL
LCD PANEL
Channel Up
Push-To-Talk (PTT)
Quiet Tag
SelCall RX
Channel Down
Microphone
Scan
Busy
Transmit
Quiet Tag
SelCall RX
SelCall/Alpha Display/
Signal Meter/Battery
Channel Display
Repeater
(Duplex)
Quiet
CTCSS/DCS
SelCall TX
DC Power Socket
Speaker Socket
Antenna Socket Rear Microphone Socket
SelCall TX
TX3510S/TX3520S FRONT PANEL CONTROLS
GENERAL OPERATIONS
Volume Control
Liquid Crystal Display
Channel Control
Push for Squelch Level/
Priority Channel
Menu/
Function
Scan/
OS-GS
Quiet/
Duplex
Squelch/
Alpha
Front Mic Input
PUSH
PRIORITY
MENU
F
PUSH
SQL LVL
SCAN
OS/GS
QUIET
DUP
SQL
ALPHA
