TX6200 I N S T R U C T I O N M A N U A L PAGE 33
Receiver Frequency Response:
- 6 dB per octave de-emphasis,
300 Hz to 3 kHz, + 1, - 3 dB.
Current Consumption:
15 mA Sleep Mode.
40 mA Muted.
180 mA Full Volume.
Conducted Spurious Emission:
< - 75 dBm
Squelch:
SQL-1: -122 dBm typical
SQL-2: -117 dBm typical
SQL-3: -112 dBm typical
Close: -124 dBm typical
MECHANICAL SPECIFICATION
& CONNECTORS
Dimensions:
135 mm (W) x 63 mm (D) x 40 mm (H)
Weight:
390 grams
Antenna:
TNC Female
Speaker/Microphone/Programming:
Speaker: 3.5 mm mono socket
Programming/Microphone: 2.5 mm
stereo socket
Battery Charging:
Trickle: 3.5 mm DC Socket
Rapid Charge: 3 plated terminals
with temperature sensor.
All values are typical unless otherwise
stated and are subject to change
without notice or obligation.
Frequency Stability:
± 5 PPM
Modulation:
FM
Maximum Deviation:
< ± 5 kHz at + 20 dB Limiting
Transmit Frequency Response:
+ 6 dB per octave 300 Hz to 3 kHz,
+ 1, - 3 dB
Audio Signal to Noise:
> 40 dB.
Current Consumption (max):
2.0 Amps.
RECEIVER
RF Bandwidth:
RF: 5 MHz
Tuneable: 117 MHz
Intermediate Frequencies:
1st: 21.4 MHz
2nd: 450 kHz
Sensitivity:
- 123 dBm for 12 dB SINAD.
Sensitivity of Receive-only Channels:
-120 dBm for 12 dB SINAD
Selectivity:
- 6 dB ± 7.5 kHz
- 63 dB ± 25 kHz
Intermodulation Immunity:
>65 dB
Blocking Immunity:
>90 dB
Spurious Response Immunity:
>70 dB
Image Rejection:
>60 dB
Audio Output Power:
0.5 watts at <10% distortion.
Audio Signal to Noise:
> 40 dB.
