PAGE 22 INSTRUCTION MANUAL TX675 / TX675
sPeCIFICAtIons
GENERAL
Frequency Range: 476.425 – 477.4125 MHz
Channel Spacing: 12.5 kHz
No of Channels: 80, (75 voice, 2 telemetry RX only, 3 for future use).
CTCSS Codes: 50
DCS Codes: 104
Dimensions: (W x H x D): 52 mm x 90 mm x 30 mm
(without antenna)
Complies with: AS/NZS 4365: 2011
POWER SUPPLY
Power Source: Li-ion rechargeable – 3.7V DC, 1600 mA
Operating Time: 14 Hours (High Power)
20 Hours (Low Power)
(Transmit 5%, Receive 5%, Standby 90%)
RECEIVER
Usable Sensitivity: -121 dBm
Maximum Audio Output: >0.5 watt max. (8 Ohm)
Modulation Distortion: <5% (1 kHz 70%)
TRANSMITTER
Transmit Power: Hi: 1.8 watts
Lo: 0.5 watt
NOTE: Specifications are typical unless otherwise indicated and may be subject to
change without notice or obligation.
