6. Fuse cable Connetion
G-Net system DASH CAM
VCC
VCC
1
Find Fuse box inside of car and then, Open up cover to find Fuse.
VCC wire : It should connect continuous power supply of fuse in fusebox
ACC wire : It should connect to power supply of fuse which is supplied with power. when turn on ignition
* Fuse box’s location inside of car is different depend on brand and car model, user be informed that need to contact shop and mechanic for installation.
Our company is not responsible for any personal carelessness.
* The colors of wires VCC, ACC, GND may be different. Please check Product manual before installation.
2
After connecting VCC, ACC on Fuse, put them into the fuse box
3
GND wire need to be connect to ground in car
(Do not connect the volt which is connected to Dash board)
4
Start Dash cam to check the operation, neatly arrange the cables With Front cam
4
09
