Chapter 3, Components and Box
TOOLS, LUBRICANTS, ADHESIVES
*Generic pliers.
*Hexagonal Screw Driver, size 1.5, 2, 2.5mm.
*4.5, 5, 5.5mm Socket wrench.
*Medium threadlocker (eg. HA116-S)
*Strong retaining compound (eg. HA115-S)
*Spray lubricant (eg. Try-Flow Oil)
*Grease ( eg. Microlube GL261)
*Cyanoacrylate adhesive
*Pitch Gauge (for set-up)
*Soldering equipment (for motor wiring)
ADDITIONAL COMPONENTS REQUIRED
*1 flybarless 3 axis control unit.
*3 cyclic servos ( Micro size SAB DS12C).
*1 tail rotor servo ( Micro size SAB DS12T).
*6 channel radio control system on 2.4 GHz.
*Batteries: 6S – 1000/1250mAh ( eg SB128 or SB129 ).
The assembly process is described in the following chapters. Each chapter provides you with the bag you will need for that chapter.
This information is printed in RED color in the top corner of the page.
INSIDE THE BOX:
Main Box: Fuselage, Landing Gear, Main Blades, Carbon Rod, Blade Holder,
ESC Support, Tail Fin, Box 1, Box 2, Manual, Product Card.
Box 1: Motor & ESC.
Box 2: Assembly Bags.
MAIN BOX
BOX 1
BOX 2
PRODUCT CARD
MANUAL
TAIL FIN
ESC SUPPORT
MAIN BLADES
BLADE HOLDER
