30
5 Accessories
G500 Series
Remove the first labels from the liner, so you can pull the liner through the guides.
Pass the label stock through the printer as shown in the illustration on the right.
Accessories
030
Tear a label
THE FIRST LABEL
THE PAPER FEED ROLLER
OF PRINTER
LABEL STOCK
THE PAPER FEED ROLLER OF PRINTER
THE PAPER FEED ROLLER OF LABEL
DISPENSER MODULE
LABEL
LINER
