1-2. Ethernet Module Specifications
ITEM
Description
CPU
32-bits RDC(x86), 133 MHz
SD
RAM
4M Bytes
Flash Memory
2M Bytes
ETHERNET
Connector
RJ-45 Connector
Standard
IEEE 802.3 10/100Base-Tx (Auto-Sense)
Protocol
ARP, IP, UDP, TCP, HTTP, DHCP, FTP, SNMP, SMTP
Server
TCP Server ; UDP Server
Setup
HTTP Browser Setup (IE & Netscape)
Security
Setup Password & Connect Password
USB Port
Connector
Dual row 8-pin header
Standard
USB 2.0 Host mode, Full speed 12M bps
POWER
DC 5V, 300mA
LED LAMP
SYS(PWR) , LAN-100 MBPS, LAN –10MBPS
ENVIRONMENT
Operating Temp: 0℃~50℃
Storage Temp : -10℃~70℃
DIMENSIONS
95 x 51.5 x 20 mm ( W x D x H )
WEIGHT
100 gm
OTHERS
Watch Dog Function, Firmware On-lined Updated Via Ethernet
USB Port connector pin assignment:
Pin 1
Vbus
Pin
3
D+
Pin
5
+5V
Pin
7
+5V(RLY)
Pin 2
GND
Pin
4
D-
Pin
6
GND
Pin
8
GND
