Godex RT200i User Manual

7
2 Printer Setup
007
2. Then place the left-hand side of the ribbon.
Load the Ribbon on the Printer
For Ribbon Supply Module
1. Place the right-hand side of ribbon first.
Right side
Push the ribbon to tighten
the spring of the holder
Align the ribbon core
to the holder
SPRING OF HOLDER
Left side
Align the notch of the ribbon core to the spoke
NOTCH OF RIBBON CORE
SPOKE
RIBBON SUPPLY MODULE

Godex RT200i Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	1727 mm
Maximum printing width	54 mm
Display	LCD
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Certification	CE (EMC), FCC Class A, CB, CCC, cUL
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Ribbon width	59 mm
Core diameter	25.4 mm
Ribbon length	110 m
Media thickness	0.06 - 0.2 mm
Maximum roll diameter	127 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %
Power requirements	100-240V, 50-60Hz
Compatible operating systems	Windows 2000, XP, Vista, 7, Windows Server 2003, 2008

Weight and Dimensions

Depth	254 mm
Width	136 mm
Height	175 mm
Weight	2000 g
