49
5 Accessories
045
4. Remove the platen
Lift up the release clips on both sides of the platen to release and pull upward the platen.
CLIP
Release the clip
Pull up the platen
5. Ribbon loading
Please see the Section 2.2 for further information about Loading The Ribbon.
6. Label loading
Please see the Section 2.3 for further information about Loading The Label Roll Module.
