AD600BM
AD600BM
AD
600BM
AD
600BM
AD600BM
AD600BM
0
180
0
180
- 29 -
- 30 -
Name of Parts Name of Parts
(2) Multi Flash
Multi:Stroboscopic flash
Number of flashes
Flash frequency
S1/S2
LCD Panel:
(3) Radio Transmission Shooting
Firing group
Channel
: Radio transmission
wireless shooting
Flash duration
(4) Slave Unit
AD600BM can be used in combination with the following accessories sold separately, so as to achieve best
photography effects: X1 Wireless Flash Trigger, FT-16 Remote Control, Softbox, Beauty Dish, Fold Up Umbrella,
Snoots, Light Stand, etc.
Separately Sold Accessories
Installing Reflector (Other Accessories)
1. Press down the Accessory Locking
Ring.
2. Insert the reflector into the Accessory
Mount and clock wise to lock it up.
Attaching Flash Tube
1. Remove the reflector or other
accessories from the flash head.
2. Match the flash tube in the Tube
Socket. Push the flash tube in until it
is securely seated into the socket.
1. Flash tube 2. Lithium battery pack 3.Battery charger 4. Power cord 5. Lamp cover 6. Instruction manual
Included Accessories
Adjusting Handle
1. When the Direction Adjusting Handle
is not pulled out, screw clockwise
while unscrew anti clockwise.
2. The Direction Adjusting Handle's rotation angle should be restrained from 0 to
180 degrees below the flash body. Please pull out the Direction Adjusting
Handle, adjust the appropriate angle, and manipulate the step 1 before
colliding with the flash body.
1 3 4 52
