Names of Parts
(A) Group Setting (B) Channel Setting (C) Low Battery Indicator
Receiver Panel
- 26 -
(A) Output Settings per Group in the M Mode; FEC Settings per Group in the TTL Mode
(B) Mode Settings (C) Group (D) Currently Selected Group (E) Channel Settings
(F) GR Grouping Icon (G) Synchronization Delay Setting Icon (H) Low Battery Indicator
(I) Single Contact Icon
AB
C
D
E
F
G
H
I
Transmitter Panel
C
B
A
Installing Batteries
As shown in the illustration, slide the battery compartment lid of the transmitter and
receiver and insert two AA batteries (sold separately)separately.
Low Battery Indication
When the battery power (2 AA
batteries <2.0V) gets low,
Status Indicator Lamp blinks
quickly (blink cycle=0.5s).
Please replace new batteries,
as low power leads to no flash
or flash missing in case of
long distance.
Battery
Names of Parts
1. Remote Cable(N1, N3) 2. Sync Cable 3.Sync Adapter
Accessories
To Next Page
