GOK SmartBox 1 Assembly And Operating Instructions

SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
8 / 16 Part No. 28 100 57 e
Menu
Input function
Input value
4.Tank
volume
Adjust the tank volume with [+] / [-] (100%). The default
setting is 0 L. The value must be set.
___________L
Please see a volume table for the highest value,
if available. For a 100 m³ cyl. buried tank, this
may for example be the value 100600 litres.
Free space: YES

Free space[%]
Free space: NO
5.Tank
height
Enter inner tank height in millimetres: e. g.: 249 cm
(max. value = 999,9 cm) (height without dome)
_________mm
Please see a volume table for the highest value,
if available. For a 100 m³ cyl. buried tank, this
may for example be the value 288 cm.
REFERENCE
Steps 6 + 7 are only required for SmartBox
®
2 and SmartBox
®
3
Menu
Input function
Input value
6.Relay 1
or
 SmartBox 2
6.Acoustic
alarm
(Buzzer)
 SmartBox 3
Switch function of relay 1 or buzzer:
ON ______%
OFF ______%
ON ______°C
OFF ______°C
Deactive
The relay does not switch in relation to
the content
Active
The relay switches in relation to the
content
ON
Forces the relay to energise (fix ON)
OFF
Forces the relay to de-energise (fix OFF)
Example of switch point setting for Active (with
hysteresis):
Enter switching points as % values from 01-99 (and/or
enter as °C value from -99 to +99 only for probe with
temperature measurement)
deactive  activate with [+] / [-] to
active  press Enter to confirm 
On 10%  ON: set with [+] / [-]  [Enter]
Off 12%  OFF: set with [+] / [-]  [Enter]
On +0°C  ON: set with [+] / [-]  [Enter]
Off +0°C  OFF: set with [+] / [-]  [Enter]
Deactivate the relay or buzzer via deactive or input
of 0% or 0°C (for On and Off).
7.Relay 2
 SmartBox
2+3
See 6. Relay 1 for the data for Relay 2
ON ______%
OFF ______%
ON ______°C
OFF ______°C
8.Exit
Press [Enter] to return to display mode
After performing entry steps 1 - 7, the programming process is completed. After confirmation
of step “8.Exit“, the device automatically returns to default display mode; the current tank
content is shown in the display.
Special functions are available under entry steps 9 to 24.
