NOTES ON PROGRAMMING
Menu
Setting
Description
9.Offset
probe
Adjusting:
Probe zero point, electric
Position / Distance from base
Unusable capacity that is not to be displayed
ESC
Exit the menu
Offset calibr.
New measurement of probe zero point (electric)
Lift probe out of the liquid beforehand.
Probe bottom gap
Distance: x cm;
normal reference is x = 0 cm, max = 99 cm
Bottom deadstock
Suction position: y cm
Normal reference is 0 cm = complete capacity.
y > 0 cm means corresponding unusable
capacity.
Default values
Reset all values to default 00.
10.Trim
height
xxx.x cm
Entry option for the reference height for the 2-
point measurement, for other probe measurement
range or for an unknown density. Subtract 1.0 cm
from the actual measured level and enter this
value.
Calibrate:No
Calibrate:Yes
If activated (Yes), the display in menu steps
“1.Measure probe” and “2.Liquid” is then "by
comparison".
If this is entered with an almost empty tank, it is
recommended that you make a correction the
next time it is filled.
11.Trim
volume
xxx.xxx L
Readjust the level display with the [+] / [-] button
Calibrate:No
Calibrate:Yes
See menu step 10.Trim height
12.Unit
L
%
m
kg
IG
UG
t
mbar
kPa
Default settings L
liter:
cubic meters:
percent:
meter:
kilogram:
imperial Gallon:
US liquid gallon:
ton:
millibar:
kilopascals:
999900 L
2.50 m³
99.50 %
2.50 m
999900 kg
219750 IG
263900 UG
2.50 t
500 mbar
50 kPa
