GOK SmartBox 1 Assembly And Operating Instructions

SmartBox
®
1 / SmartBox
®
2 / SmartBox
®
3
10 / 16 Part No. 28 100 57 e
Example 3: Buried tank, cylindrical, horizontal, for 100600 litres diesel oil
Inner height 288.6 cm, (fill level 54 cm)
SmartBox
®
3 Standard probe 0 - 250 mbar
Limit value message on the device at minimum level <25 %
Acoustic alarm - On at <25 % - Off at >27 %
Step
Entries / selection
1.Probe
250 mbar (set with [+] / [-] keys)
2.Medium
Diesel (set with [+] / [-] keys)
3.Tank shape
Cyl. > 50.000 L (set with [+] / [-] keys)
4.Tank volume
100600 L (exact value from volume table
set with [+] / [-] keys)
5.Inner tank height
288.6 cm (exact value from volume table
set with [+] / [-] keys)
6.Acoustic alarm
active

On: 25 %

Off: 27 %
7.Relay 2
deactive (set with [+] / [-] keys)
8.Exit
 press [Enter] to see the indication
Diesel
12.800 L 13 %
Tanks with inner shell
For tanks with an inner shell (e.g. cylindrical horizontal or tanks welded together in the
basement) the data in steps "4.Tank volume" and "5.Internal tank height" must be corrected.
Example: Wall thickness of the inner shell approx. 0.5 to 1.0 cm
Reduce the entry for "5.Internal tank height"  by approx. 20 %
Entry "4.Tank volume"  tank to 10 m³: Reduce vol. by 3.0 %
 Tank to 20 m³: Reduce vol. by 2.5 %
 Tank to 50 m³: Reduce vol. by 2.0 %
 Tank to 100 m³: Reduce vol. by 1.5 %
