SmartBox® 1 / SmartBox® 2 / SmartBox® 3
14 / 16 Apparaat Nr. 28 100 59 d
Pos: 61 /Anleitungen A5/ STANDARDMODULE/Über schriften/Technisc he Daten @ 1\mod_132145082 0797_610.docx @ 21006 @ @ 1
TECHNISCHE GEGEVENS
Pos: 62 /Anleitungen A5/ Elektronik/Smar tbox/1+2+3/Techni sche Daten @ 0\mod_13051225 52387_610.doc x @ 12580 @ @ 1
Indicato
r
Spanningsvoorziening: 230 V AC 50 Hz Beveiliging: IP30 of IP65 volgens
IEC 529
Vermogensafname: max. 2 VA
Meetingang: 4 – 20 mA; Uo = 20 V Oplossend
vermogen:
10 bit
Relaisuitgang: optioneel
Schakelspanning: max. 250 V AC Analoge uitgang: 0 – 5 V DC
Schakelstroom: max. 3,5 A 4 – 20 mA
Afmetingen
H x B x D in [mm]:
120x120x49 (IP30)
of
130x130x60 (IP65)
Behuizing: polystyrol (IP30) of
polycarbonaat (IP65)
Temperatuurbereik: omgeving
-10 ˚C tot +50 ˚C
Sonde (relatiefdruksonde voor het meten van de peilstand) / Standaardsonde
Bedrijfsspanning: 20 V DC Beveiliging: IP 68 volgens IEC 529
Actieve stoffen: V4A; POM;
FPM; HD-PE
Lengte van de norm
sonde (zonder kabel):
sonde:
90 mm
22 mm
Nauwkeurigheid: ± 1 %
Uitvoering standaard: 250 mbar Lengte aansluitkabel
sonde:
6 m
Inbouwpositie: hangend loodrecht of liggend horizontaal
Temperatuurbereik: omgeving bedrijfsmedia
-10 ˚C tot +60 ˚C
