| REAR PANEL
3
POWER AND OTHERS
RCA 1 Phono and GND 1
(GND signal ground)
1
RCA unbalanced
2
Micro USB (for service only)
7
IEC socket
6
Master Switch ON/OFF
5
PSU-IN (for the external
power supply)
4
LINE OUTPUTLINE INPUT
XLR balanced
3
1 2
3
4 5 6
7
REAR PANEL OVERVIEW
The PH-5 features high-quality connectors to
provide maximum versatility.
The PSU IN input is dedicated to the external
power supply to enhance even further the
performance of your PH-5.
