DESCRIPTION AND SPECIFICATIONS
3
PSU-10 has been engineered with the best quality audio-
grade components to enhance the performance of PH-10
and improve even further your system: with the dedicated
external power supply you will get the very best music
experience out of your LPs.
For PSU-10 we have chosen a dual choke design powered
by a double inductor driving the negative and positive high
current stages and featuring and inductive filter on the
analogue stage.
The PSU-10 can deliver high quality power using 4
transformers 3 of which are dedicated exclusively to the
pure power supply and with 1 separated transformer
dedicated to the inductive filter and the two chokes.
The Gold Note proprietary Dual Chokes Design perfectly
filters the signal voltages in order to eliminate all the
possible electrical pollution coming from the AC power
system.
The PSU-10 uses its massive power supply to shield the
PH-10 phono stage from electro-magnetic interferences
thus insulating it effectively from the AC power system.
The large, ultra-clean power enhances super low noise,
greater dynamic, better resolution and finer details for a
more realistic high-end audio performance and pure audio
pleasure.
The PSU-10 is a super inductive & chokes power supply designed exclusively for the PH-10 phono stage.
MAIN FEATURES
Four rail audio grade power supply
Four ultra low noise voltage regulator
+12V, +5V for logic
+/- 14V for analog with inductive noise remover
Maximum variation of output voltage: 0,05%
Line noise rejection >80dB
Common mode noise rejection >80dB
Full power response time <2,5µsec
POWER
100-240V with automatic selection, 50/60Hz
Nominal power: 25W
Dynamic power: >50W
Stand by power: <1W
DIMENSIONS AND WEIGHT
200mm L 80mm H 260mm D
Weight 3 Kg net. - 4 Kg boxed
FINISHES
Brushed Aluminium available in Black, Silver or Gold
