Follow these steps to register the play:
• - Play between knife sections 2 and knife guide 3: adjust with screw 6.
• - X play: slacken screws 5, move guide block 4 and knife guide 3. Re-tighten
screws 5.
5.3 CHANGING THE CUTTER BAR
Remove the screws fixing the knife head (D fig.1), lift the head 2 mm and slide
the cutter out from the side.
Note: when installing the knife head, make sure that the knife drive pin has no
play.
