- Fuses for Model 35-37-40-1046-1047-1247
Before changing a fuse, find and eliminate the fault that caused it to blow
The fuses protect the following circuits fig.16 (3 fig.20):
A= Front right, rear left parking light, licence plate light, 7-pin plug, multi-system
lighting. 7.5A
B= Right low beam headlight. 7.5A
C= Right and left high beam headlight, highbeam indicator light. 5A
D= Left front, right rear parking light, 7-pin plug, floodlight. 7.5A
E= Left low beam headlight. 7.5A
F= Horn. 10A
G= Hazard light. turning indicator power supply, - 30, cab connector line +30.
15A
H= Hydrostop power supply, PTO clutch switch, front drive engaged indicator
light switch, parking park engaged indicator light switch: 10A
I= Lift power supply control switch, controlled position and draft central control
unit connector: 10A
L= Cab line power supply connector +15. 15A
M= Multi-system instrument power supply, Motorstop solenoid valve. 10A
N= Hazard light power supply +15, optional connector power supply. 10A
The tractor has a knife main fuse rated at 60A situated inside the fixed cowling
(4 fig.20). This fuse protects the entire electric system.
