– Safety valve activity checkup,
– visual superficial checkup of the membrane.
Annual checkup before the pressing season:
– checkup of the peripheral metal sheet and welded spots in the framework,
– complete contents of service before every use.
12. TROUBLESHOOTING
Pressure membrane doesn't
stretch
Air-release valve isn’t closed.
Tighten up the air-release valve.
Outlet valve isn’t closed.
Tighten up the outlet valve
Air is in the water pressure
application system.
valve until the water starts running
again.
haven't fixed the problem, call the
authorized service company.
13. MATERIAL NOT COVERED WITH WARRANTY
Material, not covered with warranty:
– additional pressing net,
– additional protection bag.
14. HYDRAULIC CONNECTION DIAGRAM
14.1 MODELS VS-A, VSP-A, VSPI-A, VSP-C
1 – ball-bearing taps for the application of water in to the system with the supplementary part
for the flexible pipe,
2 – connection chamber
3 – air-releasing ball-bearing tap with the supplementary part for water outlet,
4 – service pipe to the membrane
5 – pressure membrane
6 – pressure gauge, 0-4 bar
7 – safety valve with spring, 3.0 bar
