GoMax Electronics MA-5188C - Page 22

~ 21 ~
Default Custom Code — IR2 Code: 00 FF
Custom Code — IR3 Code: 0x12 0x21
Custom Code: 0x12 0x21
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
Source 1
0xA1
0xB1
0xC1
0xD1
0xE1
0xF1
0x11
0x21
Source 2
0xA2
0xB2
0xC2
0xD2
0xE2
0xF2
0x12
0x22
Source 3
0xA3
0xB3
0xC3
0xD3
0xE3
0xF3
0x13
0x23
Source 4
0xA4
0xB4
0xC4
0xD4
0xE4
0xF4
0x14
0x24
Source 5
0xA5
0xB5
0xC5
0xD5
0xE5
0xF5
0x15
0x25
Source 6
0xA6
0xB6
0xC6
0xD6
0xE6
0xF6
0x16
0x26
Source 7
0xA7
0xB7
0xC7
0xD7
0xE7
0xF7
0x17
0x27
Source 8
0xA8
0xB8
0xC8
0xD8
0xE8
0xF8
0x18
0x28
Function
0x17
0x0A
0x0C
POWER
0x02
SOURCE SEL. 1
0x54
SOURCE SEL. 2
0x55
SOURCE SEL 3
0x56
SOURCE SEL. 4
0x01
SOURCE SEL. 5
0x57
SOURCE SEL. 6
0x58
SOURCE SEL. 7
0x59
SOURCE SEL. 8
0x06
INPUT 1
0x18
INPUT 2
0x5B
INPUT 3
0x19
INPUT 4
0x07
INPUT 5
0x1B
INPUT 6
0x5A
INPUT 7
0x1A
INPUT 8
0x04
OUTPUT 1
0x0E
OUTPUT 2
0x0D
OUTPUT 3
0x12
OUTPUT 4
0x05
OUTPUT 5
0x1C
OUTPUT 6
0x1D
OUTPUT 7
0x1F
OUTPUT 8
0x1E
IR Discrete Code

—
