Battery capacity detection
2、Low-voltage alarm and automatic shutdown
3、Hold and press the MIC button on the MIC base to turn on/off the terminal
4、RUN indicator
5、Attendance registration by button pressing or prosthesis registration
6、Speaking mode: AUTO or FIFO; hear a speaker via the headphone or built-in loudspeaker; volume is adjustable
7、Automatic video tracking and panoramic preset position; in support of SD and HD video tracking
8、Micro USB interface for charging; lithium battery is removable for batch charging
13
Front side:
5、3.5mm jack。Headphone output interface with a
3.5mm jack
1、Microphone gooseneck
6、3.5mm jack；Audio output interface with a 3.5mm
2、Priority key (red)
jack
7、Volume knob
Bottom:
Press this key to close all active delegate terminals.
This key is available for the chairman terminal only.
9. terminal number setting: Like the dial-up setting, the
3、MIC ON/OFF key
defaut is dialing up, namely 00000000.
8、Indicator Light; it blinks when the congress terminal
Function description: host ID is a code used within a
system for internal communication. Communication
can be successful only when the host ID of the
system is consistent with that of a congress terminal.
is matching with the congress server, it keeps lights on
when the congress terminal matches with the congress
server successfully. It lights green with sufficient
power, otherwise it would light red.
Within a building, set different host IDs for multiple
Left side:
wireless congress systems to avoid mutual
4、Micro USB interface for charging; the lithium
interference.
batteries can be removed and charged in batch.
Chapter 3 Compositions of the Wireless Conference System
3.1 Functions and Indicators of the Wireless Congress Terminal
3.1.1 Overview
The congress terminal is essential for a conference participant and it connects with a congress server via the
wireless AP. Functions available to participants vary with the type of a conference unit, including listening,
speaking, and requesting to speak.
Product models:
DCS-3021C-W Chairman terminal with basic discussion
DCS-3021D-W Delegate terminal with basic discussion
3.1.2 Basic Functions
3.1.3 Basic Functions
3.2 Functions and Indicators of Wireless AP
The wireless AP can transmit signal and is the transit device between the GONSIN30000 server and DSC-
3021congress terminals. The device utilizes the advanced selecting-hopping technology. The wireless AP has
super-strong emissivity and anti-interference capacity. It can transmit at all directions and is immune to any
obstacle.
Notice: one congress server can be connected with one wireless AP. At the same time. The system can connected
with WAP-30I wireless simultaneous interpretation AP in order to realize the simultaneous interpretation function.
The system is recommended to use in the medium or small conference room.
14
Product model:
WAP-30
3.2.1 Basic Functions
1、RUN indicator
2、Powered by the congress server
3、Wall mounting, bracket supporting, and ceiling mounting
3.2.2 Indicators
1.Signal indicator (when a microphone is connected to the wireless access point, this indicator will flash)
2.6P socket, for connecting with WAP-30I (for adding listening and simultaneous interpretation functions)
3.8P socket, for connecting with WAP-30( discussion function only)
（Lateral ）
DCS-3021 Congress System
Buttom
Front
Back
2
3
1
To Next Page
