User manual
1.3 Warning levels
Warnings against hazards that may result in injuries in
case of non-observance.
Warnings against hazards that may result in material
damage in case of non-observance.
2 Description and Function
2.1 Products
Your 2-way radio garden socket can be used for comfortable electronic swit-
chingdevicesviatheirpowersupplyeithermanuallyorviaremotecontrol.
TheradiosocketisequippedwithchildsafetyandoperatingLED.
The remote control has a maximum range of 30 meters and switches the 2
sockets together on or off.
2.2 Scope of Delivery
2-way radio garden socket, remote control, user manual
2.3 Operating Elements and parts
1
2
3
4
5
Fig. 3 :OperatingElementsandparts
1 Handle 2 Remote control with case
3 ON/OFF switch and sensor 4 Powersocketswithcaps
5 Floor dowel
