11
AIR C ONDITIONER/HEAT P UMP A DVANCED FEATURES M ENU
Submenu Item Indication (for Display Only; not User Modifiable)
Number of AC Stages (CL STG) Displays the number of air conditioning stages; applies to AC and HP.
Number of HP Stages (HT STG) Displays the number of heat pump stages; applies to HP only.
AC Tonnage (TONS) Displays the air conditioning tonnage; applies to AC and HP.
CONFIGURATION
Submenu Item Indication/User Modifiable Options Comments
Fault 1 (FAULT #1) Most recent AC/HP fault For display only
Fault 2 (FAULT #2) Next most recent AC/HP fault For display only
Fault 3 (FAULT #3) Next most recent AC/HP fault For display only
Fault 4 (FAULT #4) Next most recent AC/HP fault For display only
Fault 5 (FAULT #5) Next most recent AC/HP fault For display only
Fault 6 (FAULT #6) Least recent AC/HP fault For display only
Clear Fault History (CLEAR) NO or YES
Selecting "YES" clears the fault
history
NOTE: Consecutively repeated faults are shown a maximum of three (3) times.
DIAGNOSTICS
Submenu Item Indication (for Display Only; not User Modifiable)
Model Number (MOD NUM) Displays the air conditioner or heat pump model number
Serial Number (SER NUM) Displays the air conditioner or heat pump serial number (Optional)
Software (SOFTWARE) Displays the application software revision
IDENTIFICATION
Submenu Item User Modifiable Options Comments
Outdoor Air Temperature
(AIR TMP)
Displays the outdoor air temperature Sensor may or may not be
available on an air conditioner.
Check air conditioner instructions
for details.
Outdoor Coil Temperature
(COIL TMP)
Displays the outdoor coil
temperature
Applies to heat pump only.
Required for heat pump operation.
SENSORS
