Goodman MSG09CRN1N - Page 5

Unit Assembly
Ref
.
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
FRONT PANEL (M3, M5, M6, M8)211307936511
FRONT PANEL (M1, M2)211313230711
FRONT PANEL (M4, M7)211313994211
AIR CLEANER (M1, M2, M3, M4)211301021221
AIR CLEANER (M5, M6, M7, M8)211307913021
AIR FILTER (M5, M6, M7, M8)211307912131
AIR FILTER (M3, M4)211310140231
AIR FILTER (M1, M2)211313231231
ACORN NUT (M5, M6, M7, M8)211307913141
ACORN NUT (M1, M2)211313232341
REMOTE CONTROLLER (M3, M5, M7)233550900551
REMOTE CONTROLLER (M6, M8)233550900751
REMOTE CONTROLLER (M2, M4)233550913551
REMOTE CONTROLLER (M1)233550913651
FRAME PANEL (M3, M4)211302072161
FRAME PANEL (M5, M6, M7, M8)211307936861
FRAME PANEL (M1, M2)211313231561
DISPLAY PANEL (M3)211302072271
DISPLAY PANEL (M4)211302073371
DISPLAY PANEL (M2)211313231171
DISPLAY PANEL (M1)211313231771
RECEIVER WINDOW (M1, M2)211313231081
DISPLAY BOARD (M6, M8)213307904491
DISPLAY BOARD (M5, M7)213307985891
DISPLAY BOARD (M4)213325902291
DISPLAY BOARD (M1, M2)233313908791
DISPLAY BOARD (M3)233313912391
COPPER NUT GLM-A01 (M5, M6)2160033001NS
COPPER NUT GLM-B02 (M1, M2, M7, M8)2160032001NS
COPPER NUT GLM-C03 (M5, M6)2160033003NS
COPPER NUT GLM-D04 (M7, M8)2160032003NS
COPPER NUT TLM-A01 (M1, M2, M3, M4)2160032000NS
COPPER NUT TLM-C03 (M3, M4)2160032002NS
HORIZONTAL LOUVER DOWN (M3, M4)2113020724
NS
HORIZONTAL LOUVER DOWN (M5, M6, M7, M8)2113079369NS
HORIZONTAL LOUVER UP (M3, M4)2113020723NS
HORIZONTAL LOUVER UP (M5, M6, M7, M8)2113079371NS
INDOOR TEMP SENSOR (M3, M4, M6, M7, M8)2243069052NS
INDOOR TEMP SENSOR (M5)2243079040NS
RELAY UNDERLAY (M3)2113020801NS
SWITCH BOARD (M4)2133259009NS
Expanded Model Nomenclature
M1 - MSG09CRN1N
M2 - MSG09HRN1N
M3 - MSG12CRN1N
M4 - MSG12HRN1N
M5 - MSG18CRN1N
M6 - MSG18HRN1N
M7 - MSG24CRN1N
M8 - MSG24HRN1N
5 RP-457
