Goodman MSG09CRN1N - Page 7

Unit Assembly
Ref
.
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
INSTALLATION PLATE (M1, M2)212305000511
INSTALLATION PLATE (M5, M6, M7, M8)212307902611
INSTALLATION PLATE (M3, M4)212310140411
CHASSIS (M3, M4)211302072821
CHASSIS (M5, M6, M7, M8)211307938921
CHASSIS (M1)211313230221
CHASSIS (M2)211313232921
FAN MOTOR (M1, M2)224003000831
FAN MOTOR (M4)224003001131
FAN MOTOR (M3)224004043631
FAN MOTOR (M5, M6)224004061731
FAN MOTOR (M7, M8)224004165031
ASSY, CROSS FLOW FAN (M1, M2)211002000841
ASSY, CROSS FLOW FAN (M5, M6, M7, M8)211002901141
ASSY, CROSS FLOW FAN (M3, M4)211310140141
BEARING HOLDER (M5, M6, M7, M8)211010900451
BEARING HOLDER (M1, M2)227301020151
BEARING HOLDER (M3, M4)227310140151
EVAPORATOR (M3, M4)215302901661
EVAPORATOR (M1, M2)215323900461
EVAPORATOR (M5, M6)215328900161
EVAPORATOR (M7, M8)215331900061
DRAIN HOSE (M3, M4)211010201271
DRAIN HOSE (M1, M2)211010201471
DRAIN HOSE (M7, M8)211300000171
DRAIN HOSE (M5, M6)211300001171
ASSY, AIR OUT FRAME (M3, M4)211302072581
ASSY, AIR OUT FRAME (M5, M6, M7, M8)211307913481
ASSY, AIR OUT FRAME (M5, M6, M7, M8)211307937881
ASSY, AIR OUT FRAME (M1, M2)211313233481
LOUVER MOTOR (M3)224001002291
LOUVER MOTOR (M5, M6, M7, M8)224002000791
LOUVER MOTOR (M1, M2)224002001291
LOUVER MOTOR (M4)2240020033
91
VERTICAL LOUVER (M1, M2)2113132336101
VERTICAL LOUVER LRG (M5, M7)2113079375101
VERTICAL LOUVER MED (M5, M7)2113079385101
VERTICAL LOUVER SML (M5, M7)2113079374101
HORIZONTAL LOUVER (M1, M2)2113132335111
TRANSFORMER (M3)2230099001121
TRANSFORMER (M7, M8)2230099003121
TRANSFORMER (M5, M6)2230099007121
CONTROL BOARD (M1)2133139081131
CONTROL BOARD (M2)2133239032131
CONTROL BOARD (M3)2133259011131
CONTROL BOARD (M4)2133259020131
CONTROL BOARD (M5)2133289001131
CONTROL BOARD (M6)2133289002131
CONTROL BOARD (M7)2133309011131
CONTROL BOARD (M8)2133309013131
TERMINAL BLOCK (M1, M2, M4, M5, M6, M7, M8)2230145105141
TERMINAL BLOCK (M3)2243139013141
EVAPORATOR TEMP SENSOR (M3, M4, M5, M6,
M7, M8)
2243069051NS
LED INDICATOR (M1, M2)2113132309NS
LEFT COVER, CHASSIS (M3)2113020726NS
LEFT REAR COVER (CHASSIS) (M5, M6, M7, M8)2113079379NS
PROGRAM CHIP (M4)2130073954NS
PROGRAM CHIP (M2)2130073958NS
RIGHT REAR COVER (CHASSIS) (M5, M6, M7, M8)2113079380NS
WATERPROOF BOARD (M5, M6, M7, M8)2113079203NS
Expanded Model Nomenclature
M1 - MSG09CRN1N
M2 - MSG09HRN1N
M3 - MSG12CRN1N
M4 - MSG12HRN1N
M5 - MSG18CRN1N
M6 - MSG18HRN1N
M7 - MSG24CRN1N
M8 - MSG24HRN1N
7 RP-457
