Goodwe GW2500-NS - User Manual

Other manuals for Goodwe GW2500-NS

User Manual19 pages

Questions and Answers

R
Robert SmithSep 12, 2025
What to do if my Goodwe GW2500-NS Inverter shows a Utility Loss error?
- W
  Whitney BlankenshipSep 12, 2025
  If your Goodwe Inverter displays 'Utility Loss', it means there's an issue with the grid connection. First, disconnect the DC switch and AC connector. Then, measure the voltage between line and neutral to ensure it meets the inverter's grid-connected specifications. If the voltage is incorrect, check the distribution switch and grid for normal operation. If the voltage is correct, reconnect the AC and DC connectors. If the problem persists, further assistance is needed.
B
Brandon TaylorAug 25, 2025
What causes Over Temperature error on Goodwe GW2500-NS and how to fix it?
- W
  William WoodAug 25, 2025
  The 'Over Temperature' error on your Goodwe Inverter indicates that the internal temperature is higher than normal. Try to decrease the ambient temperature or move the inverter to a cooler location.
B
bakerloriAug 25, 2025
Why does my Goodwe GW2500-NS Inverter show Utility Loss?
- A
  Ashley MilesAug 26, 2025
  A 'Utility Loss' message on your Goodwe Inverter indicates a disconnection from the power grid. Check if the power grid is connected to the cable and verify the availability of the power grid.
B
Brian StricklandSep 23, 2025
What to do if my Goodwe GW2500-NS displays a Fac Failure?
- R
  Rick BarnesSep 23, 2025
  If your Goodwe Inverter displays a 'Fac Failure', the grid may not be connected. Check the grid connection cables and verify the grid's availability.
L
Luis McintyreSep 12, 2025
How to fix Button Fault on a Goodwe Inverter?
- A
  angela65Sep 12, 2025
  If the buttons on your Goodwe Inverter aren't working, remove the cover and reconnect the ribbon cable between the screen and the PCB.
P
phenrySep 18, 2025
What to do if my Goodwe GW2500-NS Inverter displays a Ground I Failure?
- T
  twalkerSep 18, 2025
  If your Goodwe Inverter shows a 'Ground I Failure', it means the ground current is too high. Try these steps: 1. Disconnect the inputs from the PV generator. 2. Check the AC system. 3. After clearing the problem, reconnect the PV panel and monitor the Inverter status. If the issue persists, contact your local service office.
K
kevin70Sep 5, 2025
Why is my Goodwe Inverter showing a Blank Screen?
- M
  Mary TaylorSep 6, 2025
  If your Goodwe Inverter screen is blank when the DC is on, try these steps: * Measure the DC voltage to ensure it's higher than the start-up voltage. * Check if the PV string poles are reversed. * Inspect the DC and AC connectors for any damage. * Disconnect both AC and DC power from the inverter, wait 15 minutes, and then reconnect.
A
Amy VelasquezSep 6, 2025
How to fix Relay Check Failure on a Goodwe Inverter?
- J
  Jason PhamSep 6, 2025
  If your Goodwe inverter is showing a Relay Check Failure, which indicates an output relay fault, try this: Switch on both the AC and DC power to the inverter. Listen carefully during the inverter's startup check. If you don't hear a relay clicking sound, contact GoodWe local service center.
M
Michael DanielsSep 18, 2025
What to do if my Goodwe GW2500-NS displays a Vac Failure?
- O
  ortizamandaSep 19, 2025
  If your Goodwe Inverter shows a 'Vac Failure', the inverter will automatically restart within 5 minutes if the grid returns to normal. Ensure the grid voltage meets the required specifications and that the neutral (N) and PE wires are securely connected. If problems continue, contact your local service office.
J
Jennifer FreemanAug 30, 2025
What to do if my Goodwe GW2500-NS shows Utility Loss?
- C
  Connor HardingAug 30, 2025
  If your Goodwe Inverter indicates a Utility Loss, it means the inverter isn't detecting a grid connection. Here's what you should do: * Ensure the AC switch is in the ‘ON’ position. If it is, use a multimeter to check the voltage at the AC connector and the main switchboard wiring to confirm the grid is active. * Verify that the L, N, and PE wires are connected to the correct pins. Adjust the wiring if necessary. * Check the ‘Vac’ value displayed on the screen against the actual grid voltage. If the values are outside the regulation limits, contact your electricity company. * Turn off both the AC and DC power to the inverter, wait 5 minutes, and then measure the impedance between L & N to ground. If the values are less than 200KΩ, contact the GoodWe local service center.

Summary

NS & DNS Series Introduction

Product Series Overview

Introduction to the GoodWe NS & DNS series of solar inverters.

Installation Guide

Mounting and Location Requirements

Provides guidelines for mounting and selecting the optimal installation location, including clearance distances.

Booting-Up Process

Inverter Booting Sequence and Settings

Guides through the inverter booting process, safety country selection, and time setting.

WiFi Monitoring Configuration Steps

Step-by-step instructions for setting up WiFi monitoring for the inverter.

EzLogger Pro LAN Setup Procedure

Instructions for configuring the Ezlogger Pro with LAN for device communication and setup.

EzLogger Pro IP Configuration Modes

Details dynamic and static IP configuration methods for the Ezlogger Pro.

Trouble Shooting

Grid and Power Quality Issues

Insulation and Leakage Faults

Warranty & Service

Standard Warranty Terms and Conditions

Details the standard manufacturer's warranty period, terms, and claim procedures for inverters and accessories.

Goodwe GW2500-NS Specifications

General

Model	GW2500-NS
Rated Power	2500 W
Max. DC Power	3000 W
Max DC Input Voltage	600 V
Number of MPPT	1
Efficiency	97.5%
Max. AC Apparent Power	2500 VA
Rated Output Voltage	230 V
THDi	<3%
Cooling Method	Natural cooling
Protection Degree	IP65
Max. PV Input Power	3000 W
Output Frequency	50/60 Hz
Operating Temperature Range	-25°C to 60°C
