Goodyear GY2248CD - Technical Data

English • Owner´s manual
33
9. TECHNICAL DATA
MODEL GY2248CD GY2248CDS GY2248CDH
Voltage 230V / 50Hz 110V-130V / 60Hz 230V / 60Hz
Power 1,5 kW / 2 hp
Tank capacity 24 L
Tank material (Boiler) Steel (AIA Approved)
Max. Air displacement 210 l/min aprox. 230 l/min aprox. 230 l/min aprox.
Max. pressure 8 bar - 115 PSI
Working speed (rpm) 2850 rpm 3450 rpm 3450 rpm
Noise level 94 dB 97 dB 97 dB
Weight 22,2kg
MODEL GY2508CD GY2508CDS GY2508CDH
Voltage 230V / 50Hz 110V-130V / 60Hz 230V / 60Hz
Power 1,5 kW / 2 hp
Tank capacity 50 L
Tank material (Boiler) Steel (AIA Approved)
Max. Air displacement 210 l/min aprox. 230 l/min aprox. 230 l/min aprox.
Max. pressure 8 bar - 115 PSI
Working speed (rpm) 2850 rpm 3450 rpm 3450 rpm
Noise level 94 dB 97 dB 97 dB
Weight 31kg
