6. START-UP AND ADJUSTMENTS
Fig. 3
Fig. 4
Fig. 5 Fig. 6
Fig. 7.1 Fig. 7.2
Before start-up
1. Attach the wheels and the foot (see previous point of assembly).
2. Screw on the air lter. (Fig. 3)
3. Check the oil level with sight glass and, if necessary, top up the oil. Use SAE 15W40 premium oil. (Fig. 4)
4. Check the correspondence between the compressor nameplate data and the actual electrical system
specications. A variation of ± 10% with respect to the nominal value is allowed.
5. Make sure the compressor pressure switch is in the o position "" .
6. Insert the power cord plug into a suitable socket (Fig. 6).
7. The transport plug (Fig. 7.1) must be replaced with the equalizing valve (Fig. 7.2), failure to do so
may result in internal damage to the compressed air generation system.
8. At this point, the compressor is ready for use.
WARNING:
READ THE INSTRUCTION MANUAL OF THE PNEUMATIC TOOL BEFORE CONNECTING IT TO THE
COMPRESSOR.
