Google Nest Power Connector User Manual

4 5
ENGLIS H
Wire labelsWire
connectors
What’s included
Nest Power
Connector
Sticky pad
Before you sta
Watch an install video at
g.co/nest/powerconnectorinstall
Professional installation
recommended
Connect with an independent installer who’s
trained to install Google Nest products
at g.co/nest/install
Get advanced instructions at
g.co/nest/powerconnectoradvanced

Google Nest Power Connector Specifications

General

Output Voltage	24V AC
Wire Gauge Compatibility	18-22 AWG
Compatibility	Nest Thermostat E
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	5% to 95% (non-condensing)
Power	20 VA
Purpose	Provides power to Nest Thermostat when no C-wire is available
