Goosky S2 - 11; 图纸和视图; 模型

step 6 步骤六
11
EN
WWW.GOO-SKY.COM
󰷂六󲾣󲶋
(M1.6x5mm)x2
Socket screw
󰷂六󲾣󲶋
(M1.6x4mm)x4
Socket screw
󰷂六󲾣󰴋󰺁󲶋
(M1.6x4mm)
Socket screw
󰷂六󲾣󰴋󰺁󲶋
(M1.6x4mm)
Socket screw
󰷂六󲾣󲶋
(M1.6x4mm)x4
Socket screw
!
󱊹󰛠
CAUTION
󱄵步骤󰅫󱬆󰴋󲒕󱱕󲶋󲽒󰅝󳫒
󰷂六󲾣󰴋󰺁󲶋
(M1.6x4mm)
Socket screw
󰷂六󲾣󰴋󰺁󲶋
(M1.6x5mm)
Socket screw
󰷂六󲾣󰴋󰺁󲶋
(M1.6x4mm)
Socket screw
󰷂六󲾣󰴋󰺁󲶋
(M1.6x5mm)
Socket screw
!
󱊹󰛠
CAUTION
󰴋󰶇󲒕󲺖󳜞󰅝󳫒󰵐󳹨󲶋
!
󱊹󰛠
CAUTION
󱬆󰴋󳖯󰥶󲒐󳖪󱦀󰔳󰿎󲁐󰴶
In this step, the M1.6*4 screws fixing the motor components
on both sides should not be completely locked in place.
After assembling the main frame components, fully lock
the 4 M1.6*4 screws on both sides of the side panel.
