Goosky S2 - 8; 图纸和视图; 模型

step 3 步骤三
8
EN
WWW.GOO-SKY.COM
󱒫󱦱󳕅󰡐( Φ4*Φ10*4 )x2
Ball Bearing-MR104ZZ
󰷂󲾣󲶋
(M2x6mm)x3
Socket screw
󰷂󲾣󲶋
(M1.6x6mm)x2
Socket screw
󱧔󲶋󲺖󰄥
installed in the outer
hole
󱧔󲶋(Φ3.175*7.3)x3
󲶋󱆞(M1.6)x3
󰷂󲾣󲶋
(M1.6x4mm)x9
Linkage Ball
M1.6 Nut
Socket screw
!
󱊹󰛠
CAUTION
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󰴋󰺁󲶋
M1.6x4mm
Socket screw
󱧔󲶋(Φ3.175*7.3)
Linkage Ball
󲠆󰴋󰨗󲞓
Servo Arm
M1.6󲶋󱆞
M1.6 Nut
CCPM舵机
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
M1.6x4mm
Socket screw
!
󱊹󰛠
CAUTION
󳕅󰡐󳰡󱺄󰵐
Bearing limit
carbon plate
󰷂󲾣󰴋󰺁󲶋
(M1.6X6)
Socket screw
󰷂󲾣󰴋󰺁󲶋
(M2X6)
Socket screw
󰽍󰵐
second floor
󰵐
Motherboard
󰷂󲾣󰴋󰺁󲶋
(M2X6)
Socket screw
󱒫󱦱󳕅󰡐( Φ4*Φ10*4 )
Ball Bearing-MR104ZZ
󱒫󱦱󳕅󰡐( Φ4*Φ10*4 )
Ball Bearing-MR104ZZ
󲠆󰴋󰬀󰶇
Servo bracket
󱊹󰛠󰽍󰵐󱱕󲺖󳜞󰮊󱊹󰛠󲑳󲡃
󰸗󲅾󰣘󱱕󰮊
CCPM servo
