step 17 步骤十七
22
EN
WWW.GOO-SKY.COM
!
󱊹󰛠
CAUTION
󰴋󰢗󲾴󰮊󱊦
󰢗󲾴󱱕󰅫󲶋
󲶋󰮜󰸹󳔽󰴋󳑼󳴳󰬀󰸹󰬇󳍈󰴶
󰴋󱿌󰳮󱴑󰸹󲔿󳔽󰑷󰈂󰢗󲾴󰴶
How to disassemble the upper case:
1: Disassemble the fixing screws on both sides.
2: The propeller is turned to the side of the fuselage, and the two blades are retracted.
3: Move the upper casing upwards and turn it 90 degrees toward the blade position, and it
can be disassembled;
