step 19 步骤十九
5V
Data
Data
飞行参数设置说明
一般飞行模式
油门
螺距
5
60 100 11.5°
4
60 65 5.5°
3
60 15 1.8°
2
60 -5 -0.6°
1
0 -20 -2.4°
IDLE 1模式
油门
螺距
5
65 100 11.5°
4
65 50 5.5°
3
65
5
0.6°
2
65 -50 -5.5°
1
65 -100 -11.5°
油门
螺距
5
73 100 11.5°
4
73 50 5.5°
3
73 0 0°
2
73 -50 -5.5°
1
73 -100 -11.5°
IDLE 2模式
General Flight Mode
IDLE 1 Mode
IDLE 2 Mode
Throttle Screw Pitch Throttle Screw Pitch Throttle Screw Pitch
Flight Parameter Setting lntroduction
CH2
CH1
CH3
3.3V
33
TX RX
5V
Data
飞控对频介绍
Introduction to flight control binding
!
CAUTION
连按3次按
长按按
Turn on the GOOSKY T8 transmitter, press the BIND button for 3 times after the
helicopter is powered on. The blue light flashes quickly. Keep the transmitter less than
one meter away from the flight control. The flight control passes self-detection when the
blue light is solid on. Then the binding is done.
Turn on the Futaba transmitter, adjust the communication protocol to (S-FHSS). Long
press and hold the BIND button when the aircraft is powered on, the blue light flashes
quickly then. Keep the transmitter less than one meter away from the flight control. The
flight control passes self-detection when the blue light is solid on. Then the binding is
done.
