Shenzhen Gooxi Technology Co., Ltd.
user's operation manual, mainly introduces the product characteristic
parameter, the system constitution, the installation way and the explanation,
this section controller storage server of Gooxi supports 1 controller module
The system is based on the integration of the 4U36 chassis and the G2SCW-4B
board.
This manual is for reference by professional system integrators and
personal computer technicians. This product should only be installed and
maintained by experienced technicians.
Manual framework
Chapter 1 Product Introduction
This chapter provides the specifications of the main components of the system
and describes the main features of the G2SCW-4B motherboard and the 4U36 chassis.
Chapter II System Interface Introduction
This chapter provides detailed description of the system interface, including
the main board's IO interface and each connector, terminal and jumper functions
and information.
Chapter 3 Detailed Controller Module Installation
This chapter provides the installation and description of the processor, memory,
PIKE card, and expansion card on the G2SCW-4B mainboard. Refer to this section for
precautions when installing or removing the processor, memory, PIKE card, expansion
card, and heat sink.
Chapter 4 Chassis Installation
This chapter provides the installation and description of the backplane, SPIB
board and fan wall on the storage server, and notes about installing or removing
the backplane, SPIB board, and fan wall. Refer to this section.
Chapter 5 Server System Installation
This chapter describes the necessary steps and precautions for using the
ST401-S36REH-G2 storage server barebones.
