Gooxi ST401-S36REH-G2 User Manual

Shenzhen Gooxi Technology Co., Ltd.
Package Size
800*580*395mm(length*width*height)
Safety certification
CE、ROHS
1.3.2 System Power
The chassis is equipped with 800W 1+1 redundant white gold efficiency power
supply and supports hot swapping and replacement.
Input AC voltage: 100V~240V;
DC output voltage: +12V, +12V_SB
Frequency: 47Hz~63Hz.
1.3.3 Heat Dissipation System
Three 12038 fans (12V/Max 1.76A)
Fan parameters:
Voltage: 8.5~13.2V, current: 1.60A, maximum 1.76A.
Power: maximum 23.2W.
Maximum speed: 3600 +/- 10% RPM.
Air flow: 4.657 m3/min (164.39 CFM), minimum 3.379 m3/min (119.3 CFM).
Pressure: 146.9538 Pa.
1.4 System View
1.4.1 Front View
