Gooxi ST401-S36REH-G2 User Manual

Shenzhen Gooxi Technology Co., Ltd.
 The system has a VGA port derived from the BMC.
 The system has two USB3.0 interfaces for users to use.
1.2 Board Features
1.2.1 Board Parameters:
The ST401-S36REH-G2 is equipped with a G2SCW-4B single-processor server
board. It is based on the Intel X86 architecture, uses the Intel Greenlow platform, is
based on the Intel PCH C23X chipset, and is compatible with the latest-generation
Skylake CPU from Intel. It is compatible with Kabylake CPUs to be released, and
supports dual channels. DDR4-2133/1866/1600 ECC UDIMMs.
The following are the main features of G2SCW-BH:
Motherboard
G2SCW-4B
processor
Intel Xeon processor E3-1200 V5/V6 series
Intel 6th Generation Core i3 /i5/i7 series
Pentium series
Celeron series
Socket (LGA1151) up to 80W CPU
chipset
Intel PCH C232 chip
Memory
(system)
Supports up to 64GB ECC DDR3-2133/1866/1600 UDIMMs,
Capacity support 2GB, 4GB, 8GB, 16GB
PCH/SATA
Supports 6 SATA3.0 6Gb/s ports
LAN
4 Intel I210-AT 1GbE LAN Controllers
System hard
disk RAID
Intel® RSTe Support software RAID 0, 1
VGA
Aspeed AST2400 Graphics
Input/output
interface
1*VGA port, 4* Gigabit Ethernet port, 1* multiplexed IPMI
network port, 1* motherboard switch, 2*USB2.0
Management
interface
IPMI 2.0 + KVM with dedicated LAN
