Indoor unit
1. Panel frame
2. Rear air intake grill
3. Front panel
4. Air purifying filter & air filter (behind)
5. Horizontal louver
6. LCD display window
7. Vertical louver
8. Manual control button (behind)
9. Remote controller
Outdoor unit
10. Drain hose, refrigerant connecting pipe
11. Connective cable
12. Stop valve
13. Fan hood
NOTE:
All the pictures in this manual are for
explanation purposes only. Your air
conditioner may be slightly different. The
actual shape shall prevail.
