Gorilla Playsets Sun Palace - Page 36

5/16 X 4"
5/16" WASHER
HEX BOLT
2 X 6 X 79-1/4"
INNER FORT SUPPORT
STEP 8: INSTALLING INNER FORT SUPPORTS
1: FIND THE TWO 2 X 6 X 79-1/4" INNER FORT SUPPORTS.
2: LINE UP THE 3/8" HOLE CLOSEST TO THE BOTTOM WITH THE BOTTOM HOLE OF THE INNER FORT SUPPORT.
3: ATTACH THE INNER FORT SUPPORT TO THE LADDER ASSEMBLY WITH 5/16 X 4" HEX BOLTS AND 5/16" WASHERS.
4: REPEAT STEPS 2 AND 3 TO FASTEN THE INNER FORT SUPPORT TO THE ROCK WALL ASSEMBLY.
36
