STEP 9: INSTALLING T-NUTS ON CORNER POSTS
1: FIND FOUR 4 X 4 X 61-1/4" CORNER POSTS.
2: USING THE DIAGRAM BELOW, INSTALL T-NUTS INTO THE APPROPRIATE HOLES. PLACE T-NUTS INTO THE HOLES OF
THE CORNER POST AND SET WITH A HAMMER.
3: THE CORNER POSTS ARE SHOWN RELEVANT TO THEIR ORIENTATION ON THE UNIT.
1
3
2
5/16" T-NUT
4
4 X 4 X 61-1/4"
CORNER POST
37
