Remove all packaging material, then inspect each item for any accidental damage
that may have occurred during shipping. You should nd each of these items in
your box:
Unpacking and Product Specs
1
3
2
ELECTRIC BIKE TOOLS: (1) LARGE WRENCH, (3)
ALLEN WRENCHES,
(1) SCREWDRIVER
BATTERY CHARGER
ITEM SPECIFICATIONS
Model EBE2
Product Dimensions 173x63x107 (cm)
Package Dimensions 139x24x72 (cm)
Max Load 264 lbs (120 kg)
Package Weight 62 lbs (28 kg)
E Bike Weight 49 lbs (22 kg)
Max Speed 20 mph
Battery/Charger Input 100-240V 50/60HZ AC Plug; Output 42V2A DC2.1
Pedal-Assist Mode Approx 43-50 miles (70-80 km)
Pure Electric Mode Approx 22-24 miles (36-40 km)
Max Angle of Climb 14 degrees
Charging Time 6-7 hours
Tire Pressure 45-65 PSI
Bell/Horn Electric Horn Installed
Charging Port Output Voltage 5V1A
Frame Material 6061 Aluminum Alloy
IP Level Ipx4
